| Item | Unit | Value |
|---|---|---|
| Overall weight | kg | 38120 |
| Rated capacity | kg | 25000 |
| Maximum lifting height | mm | 4000 |
| Maximum travelling speed （unloadedloaded） | km/h | 26/25 |
| Maximum lifting speed （unloadedloaded） | km/h | 310/280 |
| Maximum gradeability（loaded） | – | 0.27 |
| Dimensions without fork | – | 6300×3040×3995 |
| Wheel base | mm | 4250 |
| Load center | mm | 1200 |
| Minimum turning radius | – | 5890 |
| Type of mast Secondary standard type | – | / |
| Fork dimensions | mm | 2440×250×110 |
| Fork adjustment range | mm | 820-2700 |
| Optional | – | / |
PARAMETERS
