| Item | Unit | Value |
|---|---|---|
| Operating weight | Kg | 13800 |
| Rated power | kW/rpm | 72.7 |
| Engine model | – | ISUZU BB-4BG1TRP |
| Bucket capacity | m³ | 0.52 |
| Emission standard | – | National Stage Ⅱ |
| Maximum torque/speed | N.m | 337.6/1500 |
| Displacement | L | 4.329 |
| Travel speed | km/h | 5.16/3.03 |
| Swing speed | r/min | 12.3 |
| Bucket digging force | kN | 85 |
| Arm digging force | kN | 65 |
