| Item | Unit | Value |
|---|---|---|
| Drive Type | – | 6×4 |
| Kerb Mass | kg | 16300 |
| GVW | kg | 47300 |
| Max. Speed | km/h | 78 |
| Min. Turning Diameter | m | 18 |
| Grade Ability | – | ≥30% |
| Fuel Tank | L | 400 |
| Dimension | mm | 8700×2550×3380 |
| Wheelbase | mm | 4000+1400 |
| Min. Clearance | mm | 285 |
| Approach Angle | – | 27° |
| Departure Angle | – | 36° |
| Cargo size | mm | 5800×2300×1500 |
| Cabin Model | – | XG1-H |
| Left/Right Driving | – | LHD |
| AC | – | Standard |
| Person Allowed in | – | 2 |
| Engine Model | – | SC10E400Q3B |
| Emission Standard | – | EUR II |
| Displacement | L | 10.42 |
| Output Power | KW | 294 |
| Max Torque Speed | km/h | 1600 |
| Transmission Model | – | 10JSD180T |
| PTO | – | QH50 |
| Front Axle Model | – | 7.5T |
| Rear Axle Model | – | 16T |
| Main Reducer Ratio | – | 5.262 |
| Rim | – | 8.5V-20 |
| Tire | – | 12.00R20 |
PARAMETERS
