| Item | Unit | Value |
|---|---|---|
| Boom working condition max. rated lifting capacity | t | 150 |
| Max. load moment | t.m | 874.8 |
| Max.boom length | m | / |
| Boom length | m | 20-77 |
| Light boom length | – | / |
| Fixed jib length | m | 13～31 |
| Tower jib length | – | / |
| Max. dimension of single unit in transport state:L×W×H | m | 11.5×3.0×3.2 |
| Hoist winch max. single line speed | m/min | / |
| Engine model | – | / |
| Rated power | kw | 247 |
| Total vehicle mass | Main hook block, 19m boom | 128 |
| Max. mass of single unit in transport state | t | 34.5 |
