| Milling width | mm | 2300 |
| Miling depth | mm | 500 |
| Space between tools | mm | 30 |
| Quantity of tools | Piece | 200 |
| Diameter of milling wheel | mm | 1380 |
| Diesel engine Manufacturer | / | Cummins |
| Cooling mode | / | Water-cooled |
| Number of cylinders | / | 6 |
| Rated power | kW | 563 |
| Engine speed | rpm | 2100 |
| Fuel consumption: Full load | kg/h | 70 |
| Working speed | km/h | 0-2.2 |
| Traveling speed | km/h | 0-20 |
| Theoretical gradeabilityï¼working gearï¼ | % | â¥50 |
| Ground clearance | mm | 350 |
| Diesel tank | L | 930 |
| Hydraulic oil tank | L | 270 |
| Water tank | L | 200 |
| Electric system | V | 24 |
| Machineï¼LxWxHï¼ | mm | 9330Ã3140Ã3500 |
| Emission | / | China Stage â ¢ |
