| Item | Unit | Value |
|---|---|---|
| Cutter wheel torque | kN ·m | 2×120 |
| Cutter wheel speed | r/min | 0-25 |
| Trenching width | mm | 800-1800 |
| Trenching length | mm | 2800 |
| Slurry pump flow | m³/h | 450 |
| Construction depth | m | 105 |
| Hoisting force | kN | 2×390 |
| Speed | m/min | 0-66 |
| Wire rope diameter | mm | 36 |
| Model | / | CAT-C18 |
| Power | kW@RPM | 571@1900 |
| Rated power | kW | / |
| Cooling method | / | / |
| Track retracted-extended width | mm | 4050-5500 |
| Track length | mm | 7280 |
| Track shoe width | mm | 1000 |
| Working radius | mm | 5300-5900 |
| Working dimensions | mm | 11500×6530×18900 |
| Total operating weight | ton | 185 |
PARAMETERS
