| Item | Unit | Value |
|---|---|---|
| Max. load capacity | t | 80 |
| Telescopic boom | m | 50.5 |
| Number of axles | – | 4 |
| Max. hoist height | m | 65 |
| Max.load moment | kN.m | 2965 |
| Drive engine model | – | WP10HG350E670 |
| Drive engine power | kw | 257 |
| Drive/Steering | – | 8x4x4 |
| Driving speed | km/h | 48 |
| Dead Weight in Travel State | kg | 46900 |
| Dimensions | mm | 14985×2800×3790 |
| Emission standard | – | BS-V |
