| Item | Unit | Value |
|---|---|---|
| Operating weight | Kg | 15900 |
| Rated power | kW/rpm | 90 |
| Engine model | – | Cummins B4.5 |
| Bucket capacity | m³ | 0.6 |
| Emission standard | – | Tier 4 Final |
| Maximum torque/speed | N.m | 500/1500 |
| Displacement | L | 4.5 |
| Travel speed | km/h | 4.7/2.9 |
| Swing speed | r/min | 11.3 |
| Bucket digging force | kN | 107 |
| Arm digging force | kN | 80 |
