| Item | Unit | Value |
|---|---|---|
| Silo volume | m³ | 10（maximum12） |
| Asphalt tank capacity | L | 4000 |
| Volume of water tank | L | 4000 |
| Volume of filler box | L | 800（2×400） |
| Paving width | m | 2.4-4.2 |
| Paving thickness | mm | 3-15 |
| Working speed | km/h | 1.5-3 |
| Model | – | Howo ZZ1257N4347E1（China Ⅴ） |
| Engine type | – | WP10.350E53 |
| Engine power | kW/r/min | 257/1900 |
| Overall dimension | mm | 11900×2550×3355 |
| Curb weight | kg | 20500 |
XF1003
- Silo volume 10（maximum12） m³
- Asphalt tank capacity 4000 L
- Volume of water tank 4000 L
