| Milling width | mm | 2100 |
| Miling depth | mm | 0-400 |
| Space between tools | mm | 18 |
| Quantity of tools | Piece | 144 |
| Diameter of milling wheel | mm | 1380 |
| Diesel engine Manufacturer | / | WEICHAI |
| Cooling mode | / | Water-cooling + air-air inter-cooling |
| Number of cylinders | / | 6 |
| Rated power | kW | 353 |
| Engine speed | rpm | 2100 |
| Fuel consumption: Full load | kg/h | 74 |
| Working speed | km/h | 0-3.2 |
| Traveling speed | km/h | 0-23 |
| Theoretical gradeability（working gear） | % | 20 |
| Ground clearance | mm | 350 |
| Diesel tank | L | 650 |
| Hydraulic oil tank | L | 300 |
| Water tank | L | 200 |
| Electric system | V | 24 |
| Machine（LxWxH） | mm | 9230×3160×3450 |
| Emission | / | China Stage Ⅲ |
